10GBASE-SR SFP+ Duplex LC 850nm 300m Transceiver
SFP+ 10Gbps transceiver is designed to transmit and receive optical data over multi- mode optical fiber for link length 300m, its electrical interface is compliant to SFI electrical specifications. The transmitter input and receiver output impedance is 100 Ohms differential. Data lines are internally AC coupled. The module provides differential termination and reduce differential to common mode conversion for quality signal termination and low EMI.
| Part Number | GL10-MM850SRC/I | Tx Power (dBm) | -7.3~-1 |
| Product | SFP+ SR | Sensitivity (dbm) | ≤-11.1 |
| Max Data Rate | 10.3Gbps | Distance | 300m |
| Wavelength | 850nm | Connector | Duplex LC |
| Laser Type (TX/RX) | VCSEL/PIN | Temp | 0~70 ℃/-40~85℃ |
- 10GBASE-SR/SW
- SFP+ Hot pluggable
- LC Duplex optical interface
- 850nm VCSEL transmitter, PIN receiver
- Compliant with SFP+ MSA SFF-8431, SFF-8432
- Low power consumption
- All-metal housing for superior EMI performance
- Advanced firmware allows encryption
- RoHS compliant
- Operating case temperature:
Commercial:0 to 70 °C
Industrial: -40 to 85 °C
FAQ About SFP+ SR
We have 2 factories, one in Zhejiang with an area of over 5000 square meters, and one in Shenzhen, which is also our R&D center.
We can accept small quantity,even 1pc. MOQ:1pc
Bank transfer,T/T,PayPal,and ect.,we can talk about it.
Yes,please send inquiry to us so that we can have a detailed discussion.
For usual products ,we keep stock,could ship 1-3 days after receiving your advance payment.For big quanity and special
products,please contact us.
Yes,we have professional engineers to test all devices before shipping.Our product inspection also conforms to FCC/CE/RoHS
