OSFP 800G-SR8 850nm MPO-12/APC 50M MMF optical transceive
The 800G OSFP SR8 Optical Module is a high-performance network communications component designed for data centers, supporting data rates of 800Gbps. The module uses 100G PAM4 modulation technology and VCSEL lasers to enable transmission distances of up to 100 meters over multimode fiber (MMF).
| Part Number | GL8H-OSMM85SR8C | Laser Type (TX/RX) | VCSEL/PIN |
| Product | 800G OSFP SR8 | Tx Power (dBm) | -4.6~4 |
| Max Data Rate | 850Gbps (8x 106.25Gbps) | Rx Power (dBm) | -6.4 |
| Wavelength | 850nm | Distance | 30m OM3 / 50m OM4 |
| Connector | MPO-12/APC | Temp | 0~70°C |
- Leaf-Spine Data Center Fabrics
- Top-of-Rack (ToR) Connectivity
- Cloud Infrastructure
- AI/ML Workloads
- Metro & Campus Networks
- Edge Data Centers: Compact, high-speed modules for edge aggregation sites
- Aggregate Data Rate: 800 Gbps over eight 100 Gbps PAM4 lanes
- Form Factor: OSFP MSA compliant, hot-swappable module
- Connector: Dual MPO-12 fiber interface
- Modulation: PAM4 signaling for doubled spectral efficiency
- Standards Compliance: IEEE 802.3bs/802.3ck, OSFP MSA, RoHS
FAQ About 800G OSFP SR8 Optical Transceiver
The 800G OSFP SR8 optical transceiver excels in high-density data center fabrics, top-of-rack aggregation, and short-reach leaf-spine links where 50m multi-mode fiber performance and PAM4 efficiency are critical.
FibreCross is a leading 800G OSFP SR8 supplier, offering fully compliant modules, rigorous quality testing, and global support for hyperscale and enterprise networks.
Yes,we have professional engineers to test all devices before shipping.Our product inspection also conforms to FCC/CE/RoHS
The 800G SR8 transceiver price depends on order volume, customization (e.g., extended temperature grading), and current market demand for high-speed optics—contact sales for a tailored quote.
You can buy high-quality 800G OSFP SR8 optical transceiver directly through FibreCross’s website – we can ensure fast delivery and bulk discounts.
